help! phat cat p90's with 2 volumes and a 3 way tele style switch

[CrustyBits]

I just finished my first build. (A warmoth telemaster/two Seymour Duncan phat cats and a 3 way tele switch with two volumes/no tone) I've wired it incorrectly somehow; it only makes humming noise with no string sound at all. I'm not sure what I need to do to fix it. I'd be grateful for any suggestions.... I think my problem may be that I drew up my diagram with a Gibson style switch but I need a 3 way tele blade type switch diagram. The problem is I don't understand how I should wire up the swtich??



[Artie]

Re: help! phat cat p90's with 2 volumes and a 3 way tele style switch

Simply take the two wires that go to the 3-way, and transpose them to this standard Tele diagram:

Tele_Standard.pdf



[CrustyBits]

Re: help! phat cat p90's with 2 volumes and a 3 way tele style switch

Thanks...I’ll give it a shot
