Is this wiring diagram correct and accurate?

[357mag]

Just in case I decide to rewire my Epiphone Les Paul with a pot wiring harness and a new switch harness is this Duncan diagram accurate and correct to your knowledge? Here is what I printed out:

https://www.seymourduncan.com/resources/pickup/wiring-diagrams



[357mag]

Sorry it did not list the specific diagram when I copied and pasted. But the diagram is for 2 humbuckers, 2 volumes, 2 tones, and a 3 way toggle switch. Just wondering if I followed it everything would work properly.



[jeremy]

looks ok to me



[beaubrummels]

It would work provided you are using Duncan pickups. To my knowledge, Epiphone pickups follow Gibson wire colors, which are different.



[357mag]

Okay Thank You. I do not have push-pull pots or anything like that. I would just solder the red and white wires together and tape them off.



[beaubrummels]

Okay Thank You. I do not have push-pull pots or anything like that. I would just solder the red and white wires together and tape them off.

Not if you are using Gibson/Epiphone pickups. Are you using Duncan pickups? Or stock Epiphone pickups?



[357mag]

I'm using Duncans.
